   1 // t01.c
   2 // v0.1 KHL 2009-04-21
   3 // gcc -o t01 t01.c -lm -lgd ; ./t01
   4 // static drawing, though slow to compute
   5 // earth and toroid around orbit
   6
   7 #define TITLE    "M288, 1 center orbit"
   8 #define GIFOUT   "t01.gif"
   9 #define DELTANG 0.2
  10 #define ORBWIDTH  9
  11 #define ANG0      0
  12 #define ANG1     90
  13 #define ANG2    142
  14 #define NELIP    32
  15
  16 #include "tor00.hc"
  17
  18 int main () {
  19    double  t_ang ;
  20    int     e_cnt ;
  21    int     orb ;
  22    int     norb ;
  23
  24    gdPoint ellipse[NELIP+2];
  25
  26    displaystart();
  27    torstart();
  28
  29    gdImageGifAnimBegin( im1, gifout, 1, -1 ) ; // no repeat
  30    // gdImageGifAnimBegin( im1, gifout, 1,  4 ) ; // repeat 4 times
  31    // gdImageGifAnimBegin( im1, gifout, 1,  0 ) ; // continuous repeat
  32
  33    framestart(    90, TITLE );
  34
  35    for( t_ang=-ANG1 ; t_ang < ANG1 ; t_ang += DELTANG ) {
  36       double  angle_rad=DEG2RAD( t_ang );
  37       double  tox = -major*sin( angle_rad );
  38       double  toz = -major*cos( angle_rad );
  39       gdPoint pto = sr0( tox, 0.0, toz );
  40       gdImageFilledEllipse( im, pto.x, pto.y, ORBWIDTH, ORBWIDTH, tc[0]);
  41    }
  42    drawearth();
  43
  44    for( t_ang=ANG1 ; t_ang < 360-ANG1 ; t_ang += DELTANG ) {
  45       double  angle_rad=DEG2RAD( t_ang );
  46       double  tox = -major*sin( angle_rad );
  47       double  toz = -major*cos( angle_rad );
  48       gdPoint pto = sr0( tox, 0.0, toz );
  49       gdImageFilledEllipse( im, pto.x, pto.y, ORBWIDTH, ORBWIDTH, tc[0]);
  50    }
  51
  52    frameend();
  53    displayend();
  54    return 0;
  55 }
